22207CE4NSKSpherical Roller

Name: NSK 22207CE4 Spherical Roller Bearing
Brand: NSK
SKU: 22207CE4

22207CE4 is a NSK spherical roller bearing, bore 35 mm, O.D. 72 mm, width 23 mm, dynamic rating 15,500 lbs. Dimensions, drawing, interchanges and price.

Request a quote WhatsApp Email us Search the catalog

Bore d35mm

Outside dia. D72mm

Width B23mm

Dynamic Cr15,500lbs

Static C0r15,900lbs

Limiting speed5,300rpm

Weight0.422kg

Cr / C0r0.97

Mean dia. dm53.5mm

Original catalogue drawing - NSK catalogue, page 71

22207CE4 NSK Spherical Roller bearing catalogue drawing

Scanned from the manufacturer catalogue page listing this part number. All part numbers printed on that table share the same drawing.

Scale cross-section

Blue = inner / outer ring, yellow = rolling element. Drawn to scale from this part's own dimensions for selection reference only - not a manufacturing or assembly drawing.

Dimension table (mm / inch)

Symbol	Dimension	mm	inch
d	Bore diameter	35	1.378
D	Outside diameter	72	2.8346
B	Inner-ring / bearing width	23	0.9055

Notes

Weights are given in kg. Load ratings are shown in both the original catalogue units and the converted value (1 N = 0.2248 lbf). Data is provided for selection reference only - confirm against the latest official catalogue before ordering.

Main dimensions

Bore d (mm)	35
Bore d (in)	1.3780
Outside dia. D (mm)	72
Outside dia. D (in)	2.8346
Width B (mm)	23
Width B (in)	0.9055

Load ratings & speeds

Basic dynamic load rating Cr (lbs)	15500
Basic static load rating Cor (lbs)	15900
Limiting speed - grease (rpm)	5,300
Limiting speed - oil (rpm)	6,700

Weight

Weight (kg)	0.422

Mounting dimensions (fillets / shoulders)

Chamfer r (in)	0.039
Shaft shoulder da min (in)	1.65
Shaft shoulder da max (in)	1.69
Housing shoulder Da min (in)	2.46
Housing shoulder Da max (in)	2.56

Bearing life (ISO 281 basic rating life)

C / P	Equivalent load P (N)	L₁₀ (10⁶ rev)	L_10h at 1,700 rpm
4	17,237	102	996
6	11,491	392	3,848
8	8,618	1,024	10,039
10	6,895	2,154	21,122
15	4,596	8,323	81,603

Basic rating life per ISO 281: L₁₀ = (C/P)^10/3 with C = 68,947 N. Hours = L₁₀ x 10⁶ / (60n). Life-modification factors for lubrication, contamination and temperature (a_ISO) are not included.

Source & traceability

Brand	NSK
Source catalogue	NSK inch product catalogue
Catalogue page	p.73 (dimensions) / p.74 (ratings)

Dimensions in inches and millimetres, load ratings in lbs.

Interchange - same dimensions, other brands

Designation	Brand	Type	d	D	B/T	Dyn. rating	kg
2207-2RS-TVH	FAG	Ball	35	72	23	16 kN	0.442
2207-K-2RS-TVH-C3	FAG	Ball	35	72	23	16 kN	0.432
2207-K-TVH-C3	FAG	Ball	35	72	23	33 kN	0.38
2207-TVH	FAG	Ball	35	72	23	33 kN	0.389
4207-B-TVH	FAG	Ball	35	72	23	39.5 kN	0.45
62207-2RSR	FAG	Ball	35	72	23	27.5 kN	0.384
NJ2207-E-TVP2	FAG	Cylindrical Roller	35	72	23	72 kN	0.416
NJ2207-E-XL-TVP2	FAG	Cylindrical Roller	35	72	23	73 kN	0.416
NU2207-E-TVP2	FAG	Cylindrical Roller	35	72	23	72 kN	0.406
NU2207-E-XL-TVP2	FAG	Cylindrical Roller	35	72	23	73 kN	0.406

Same dimensions, same brand

Designation	Brand	Type	d	D	B/T	Dyn. rating	kg
2207	NSK	Ball	35	72	23	7,190 lbs	0.399
2207	NSK	Cylindrical Roller	35	72	23	11,000 lbs	0.408
NU2207E	NSK	Cylindrical Roller	35	72	23	76 kN	0.4
22207HE4	NSK	Spherical Roller	35	72	23	17,700 lbs	0.386
HR32207	NSK	Tapered Roller	35	72	23	86.5 kN	0.456
HR32207C	NSK	Tapered Roller	35	72	23	13,600 lbs	0.431
HR32207J	NSK	Tapered Roller	35	72	23	15,800 lbs	0.458

Nearby bore sizes

Designation	Brand	Type	d	D	B/T	Dyn. rating	kg
22207HE4	NSK	Spherical Roller	35	72	23	17,700 lbs	0.386
22206CE4	NSK	Spherical Roller	30	62	20	11,300 lbs	0.268
22206HE4	NSK	Spherical Roller	30	62	20	13,200 lbs	0.249
21308EAE4	NSK	Spherical Roller	40	90	23	118 kN	0.73
22208EAE4	NSK	Spherical Roller	40	80	23	20,281 lbs	0.526
22208HE4	NSK	Spherical Roller	40	80	23	20,200 lbs	0.467
22308CAME4	NSK	Spherical Roller	40	90	33	27,400 lbs	0.984
22308EAE4	NSK	Spherical Roller	40	90	33	30,642 lbs	1.016
